EIW/180 QZYI-1 Polyesterimide Enameled Aluminum Round Wire

Product Introduction: EIW/180 QZYI-1 Polyesterimide Enameled Aluminum Round Wire
The EIW/180 QZYI-1 wire is a high-performance enameled aluminum round wire designed for applications requiring robust thermal and electrical properties. With a thermal class of 180°C, it offers excellent thermal stability and electrical insulation, making it suitable for use in electric motors, transformers, and other high-temperature environments.

Product Description

Trust LQ TECHNOLOGIES(WUXI)LTD for enameled wires that combine superior conductivity with exceptional durability. Our products are designed to withstand high temperatures and mechanical stress, ensuring long-term reliability.

Parameter

At least four of the five samples with a conductor nominal diameter of 2.500 mm or more shall not break down at a voltage less than or equal to that specified in Table.

Overview

EIW/180 QZYI-1 Polyesterimide Enameled Aluminum Round Wire is a high-performance electrical insulation material designed for applications that require robust thermal and mechanical properties. This wire features a thermal class of 180°C, making it suitable for high-temperature environments and demanding industrial applications.

Specifications

Conductor Material: Aluminum

Insulation Material: Polyesterimide resin

Thermal Class: 180°C

Diameter Range: 0.15mm to 6.00mm

Standard Compliance: IEC 60317-15

Certifications: ISO 9001, RoHS

Performance Data

Thermal Resistance: The wire can operate continuously at temperatures up to 180°C, providing excellent thermal stability.

Mechanical Strength: The polyesterimide enamel coating offers superior mechanical strength and flexibility, ensuring the wire remains intact during winding and bending processes.

Electrical Insulation: The insulation properties of the polyesterimide enamel ensure high dielectric strength, with a minimum breakdown voltage of 1000V at room temperature and 750V at high temperature for Grade 1 insulation.

Chemical Resistance: The enamel coating is resistant to common solvents and chemicals, enhancing the wire's durability and longevity.

Applications

Transformers: Suitable for use in oil-immersed and dry-type transformers.

Motors: Ideal for electric motors, including those used in household appliances, industrial equipment, and power tools.

Electrical Equipment: Widely used in reactors, microwave ovens, and other high-voltage electrical devices.

Packaging and Delivery

Packaging: Available in various spool sizes, including PT-4 (1-2kgs), PT-10 (3-4kgs), PT-15 (5-6kgs), PT-25 (10-12kgs), PT-30 (15-17kgs), PT-60 (25-28kgs), and PT-200 (65-75kgs). Outer packaging is typically wooden pallets or cartons.

Delivery: Standard delivery time is 5-7 days if the goods are in stock. For custom orders, delivery can take 7-14 days after order confirmation.

Quality Assurance

Testing: The wire undergoes rigorous testing to ensure compliance with international standards. Tests include thermal shock, softening breakdown, and solvent resistance.

Certificates: The product is certified by ISO 9001 and RoHS, ensuring high-quality manufacturing and environmental compliance.
